ได้ในเครื่องเดียวเหมาะสำหรับทุกอุตสาหกรรม มาพร้อมกับแบตเตอรี่ขนาด 3,100 mAh
ของแท้ประกัน1ปี
Specification
Specifications
Physical Characteristics
Dimensions
Corded: 7.3 in. H x 3.0 in. W x 5.2 in. D 18.5 cm H x 7.6 cm W x 13.2 cm D Cordless: 7.3 in. H x 3.0 in. W x 5.6 in. D 18.5 cm H x 7.6 cm W x 14.2 cm D
PowerPrecision+ 3100 mAh Li-Ion rechargeable battery
User Indicators
Direct decode indicator; LEDs; beeper; vibration
Performance Characteristics
Scans per Full Charge
70,000+
Illumination
One (1) Hyper Red 660nm LED
Imager Field of View
Horizontal: 42°, Vertical: 28°
Image Sensor
1,280 x 800 pixels
Minimum Print Contrast
15% minimum reflective difference
Skew/Pitch/Roll
Skew: ± 60°; Pitch: ± 60°; Roll: ± 360°
decode capabilities***
1D
Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma)
2D
PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Chinese Sensible (Han Xin), Postal Codes
User Environment
Operating Temp.
Corded: -22° F to 122° F/-30° C to 50° C Cordless: -4° F to 122° F/-20° C to 50° C
Storage Temp.
-40° F to 158° F/-40° C to 70° C
Humidity
5% to 95% condensing
Drop Specification
Withstands multiple 8.0 ft. / 2.4 m drops to concrete
Tumble Specification
5,000 tumbles @ 3.3 ft. (1 m)
Sealing
Scanner: IP65 and IP67; FLB cradle: IP65
ESD
Per EN61000-4-2, ±25 KV air discharge, ±10 KV direct discharge, ±10 KV indirect discharge
utilities and maintenance (continued)
Scanner SDK
Generates a fully-featured scanner application, including documentation, drivers, test utilities and sample source code. For more information, visit www.zebra.com/windowsSDK
Scanner Management Service (SMS)
Remotely manages your Zebra scanner and queries its asset information. For more information, visit www.zebra.com/sms
WIRELESS CONNECTIVITY
Bluetooth Radio
Bluetooth Class 1, Version 4.0 (LE), serial port and HID profiles
Data Rate
3 Mbit/s (2.1 Mbit/s) for Classic Bluetooth 1 Mbit/s (0.27 Mbit/s) for Low Energy
Radio Range
Direct line of sight in open air : Class 1: Up to 300 ft. (100.0 m) Class 2: Up to 30 ft. (10.0 m)
Regulatory
Environmental
RoHS EN 50581: 2012
Electrical Safety
EU Safety: EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + AC 2011 + A2: 2013; International Safety: IEC 60950-1: 2005 + A1: 2009 + A2: 2013 US/Canada Safety: UL 60950-1, second edition, CAN/CSA-C22.2 No. 60950-1-07
LED Safety
International LED Safety: IEC 62471: 2006 (Ed.1.0); EN 62471: 2008 (LED)
EMI/RFI
IT Emissions: EN 55022: 2010/AC: 2011 (Class B) IT Immunity: EN 55024: 2010 Heavy Industrial: EN 61000-6-2: 2005/AC:2005 Harmonic Current Emissions: EN 61000-3-2: 2006 + A1: 2009 + A2: 2009 (Class B) Voltage Fluctuation and Flicker: EN 61000-3-3: 2013 Medical Electrical Equipment: EN 60601-1-2: 2007/AC: 2010, IEC 60601-1-2: 2007 (Modified) Radio Frequency Devices: 47 CFR Part 15, Subpart B, Class B Digital Apparatus: ICES-003 Issue 5, Class B
